Tiny Slider 2 is actually a vanilla JavaScript carousel but that can still be used with jQuery. It's actually the recommended carousel from the good old "Owl Carousel", which is now deprecated.
Features
| Carousel * | Gallery | ||||
|---|---|---|---|---|---|
| Horizontal * | Vertical | ||||
| Percentage Width * | Fixed Width | Auto Width | |||
| Loop | ✓ | ✓ | ✓ | ✓ | ✓ |
| Rewind | ✓ | ✓ | ✓ | ✓ | |
| Slide by | ✓ | ✓ | ✓ | ✓ | |
| Gutter | ✓ | ✓ | ✓ | ✓ | ✓ |
| Edge padding | ✓ | ✓ | ✓ | ✓ | |
| Center (v2.9.2+) | ✓ | ✓ | ✓ | ||
| Responsive | ✓ | ✓ | ✓ | ✓ | ✓ |
| Lazyload | ✓ | ✓ | ✓ | ✓ | ✓ |
| Autoplay | ✓ | ✓ | ✓ | ✓ | ✓ |
| Auto height | ✓ | ✓ | ✓ | ✓ | ✓ |
| Touch/drag | ✓ | ✓ | ✓ | ✓ | ✓ |
| Arrow keys | ✓ | ✓ | ✓ | ✓ | ✓ |
| Customize controls/nav | ✓ | ✓ | ✓ | ✓ | ✓ |
| Accessibility | ✓ | ✓ | ✓ | ✓ | ✓ |
| Respond to DOM visibility changes | ✓ | ✓ | ✓ | ✓ | ✓ |
| Custom events | ✓ | ✓ | ✓ | ✓ | ✓ |
| Nested | ✓ | ✓ | ✓ | ✓ | ✓ |
Browser Support
Desktop: Firefox 8+ ✓ Chrome 15+ ✓ (Should works on Chrome 4-14 as well, but I couldn't test it.) Safari 4+ ✓ Opera 12.1+ ✓ IE 8+ ✓
Mobile: Android Browser 4.2+ ✓ Chrome Mobile 63+ ✓ Firefox Mobile 28+ ✓ Maxthon 4+ ✓
Source: github.com
1. INCLUDE JS AND CSS FILES
<link rel="stylesheet" href="https://cdnjs.cloudflare.com/ajax/libs/tiny-slider/2.9.4/tiny-slider.css"> <script src="https://cdnjs.cloudflare.com/ajax/libs/tiny-slider/2.9.2/min/tiny-slider.js"></script>
2. HTML
<div class="my-slider"> <div></div> <div></div> <div></div> </div>
3. JAVASCRIPT
var slider = tns({
container: '.my-slider',
items: 3,
slideBy: 'page',
autoplay: true
});
4. OPTIONS
| Option | Type | Description |
|---|---|---|
| container | Node | String |
Default: '.slider'. The slider container element or selector. |
| mode | "carousel" | "gallery" |
Default: "carousel". Controls animation behaviour. With carousel everything slides to the side, while gallery uses fade animations and changes all slides at once. |
| axis | "horizontal" | "vertical" |
Default: "horizontal". The axis of the slider. |
| items | positive number |
Default: 1. Number of slides being displayed in the viewport. If slides less or equal than items, the slider won't be initialized. |
| gutter | positive integer |
Default: 0. Space between slides (in "px"). |
| edgePadding | positive integer |
Default: 0. Space on the outside (in "px"). |
| fixedWidth | positive integer | false |
Default: false. Controls width attribute of the slides. |
| autoWidth | Boolean |
Default: false. If true, the width of each slide will be its natural width as a inline-block box. |
| viewportMax (was fixedWidthViewportWidth) | positive integer | false |
Default: false. Maximum viewport width for fixedWidth/autoWidth. |
| slideBy | positive number | "page" |
Default: 1. Number of slides going on one "click". |
| center (v2.9.2+) | Boolean |
Default: false. Center the active slide in the viewport. |
| controls | Boolean |
Default: true. Controls the display and functionalities of controls components (prev/next buttons). If true, display the controls and add all functionalities. For better accessibility, when a prev/next button is focused, user will be able to control the slider using left/right arrow keys. |
| controlsPosition | "top" | "bottom" |
Default: "top". Controls controls position. |
| controlsText | (Text | Markup) Array |
Default: ["prev", "next"]. Text or markup in the prev/next buttons. |
| controlsContainer | Node | String | false |
Default: false. The container element/selector around the prev/next buttons. controlsContainer must have at least 2 child elements. |
| prevButton | Node | String | false |
Default: false. Customized previous buttons. This option will be ignored if controlsContainer is a Node element or a CSS selector. |
| nextButton | Node | String | false |
Default: false. Customized next buttons. This option will be ignored if controlsContainer is a Node element or a CSS selector. |
| nav | Boolean |
Default: true. Controls the display and functionalities of nav components (dots). If true, display the nav and add all functionalities. |
| navPosition | "top" | "bottom" |
Default: "top". Controls nav position. |
| navContainer | Node | String | false |
Default: false. The container element/selector around the dots. navContainer must have at least same number of children as the slides. |
| navAsThumbnails | Boolean |
Default: false. Indicate if the dots are thumbnails. If true, they will always be visible even when more than 1 slides displayed in the viewport. |
| arrowKeys | Boolean |
Default: false. Allows using arrow keys to switch slides. |
| speed | positive integer |
Default: 300. Speed of the slide animation (in "ms"). |
| autoplay | Boolean |
Default: false. Toggles the automatic change of slides. |
| autoplayPosition | "top" | "bottom" |
Default: "top". Controls autoplay position. |
| autoplayTimeout | positive integer |
Default: 5000. Time between 2 autoplay slides change (in "ms"). |
| autoplayDirection | "forward" | "backward" |
Default: "forward". Direction of slide movement (ascending/descending the slide index). |
| autoplayText | Array (Text | Markup) |
Default: ["start", "stop"]. Text or markup in the autoplay start/stop button. |
| autoplayHoverPause | Boolean |
Default: false. Stops sliding on mouseover. |
| autoplayButton | Node | String | false |
Default: false. The customized autoplay start/stop button or selector. |
| autoplayButtonOutput | Boolean |
Default: true. Output autoplayButton markup when autoplay is true but a customized autoplayButton is not provided. |
| autoplayResetOnVisibility | Boolean |
Default: true. Pauses the sliding when the page is invisible and resumes it when the page become visiable again. (Page Visibility API) |
| animateIn | String |
Default: "tns-fadeIn". Name of intro animation class. |
| animateOut | String |
Default: "tns-fadeOut". Name of outro animation class. |
| animateNormal | String |
Default: "tns-normal". Name of default animation class. |
| animateDelay | positive integer | false |
Default: false. Time between each gallery animation (in "ms"). |
| loop | Boolean |
Default: true. Moves throughout all the slides seamlessly. |
| rewind | Boolean |
Default: false. Moves to the opposite edge when reaching the first or last slide. |
| autoHeight | Boolean |
Default: false. Height of slider container changes according to each slide's height. |
| responsive |
Object: { breakpoint: { key: value } } | false |
Default: false. Breakpoint: Integer. Defines options for different viewport widths (see Responsive Options). |
| lazyload | Boolean |
Default: false. Enables lazyloading images that are currently not viewed, thus saving bandwidth (see demo). NOTE: + Class .tns-lazy-img need to be set on every image you want to lazyload if option lazyloadSelector is not specified; + data-src attribute with its value of the real image src is required; + width attribute for every image is required for autoWidth slider. |
| lazyloadSelector (v2.9.1+) | String |
Default: '.tns-lazy-img'. The CSS selector for lazyload images. |
| touch | Boolean |
Default: true. Activates input detection for touch devices. |
| mouseDrag | Boolean |
Default: false. Changing slides by dragging them. |
| swipeAngle | positive integer | Boolean |
Default: 15. Swipe or drag will not be triggered if the angle is not inside the range when set. |
| preventActionWhenRunning (v2.9.1+) | Boolean |
Default: false. Prevent next transition while slider is transforming. |
| preventScrollOnTouch (v2.9.1+) | "auto" | "force" | false |
Default: false. Prevent page from scrolling on touchmove. If set to "auto", the slider will first check if the touch direction matches the slider axis, then decide whether prevent the page scrolling or not. If set to "force", the slider will always prevent the page scrolling. |
| nested | "inner" | "outer" | false |
Default: false. Define the relationship between nested sliders. (see demo) Make sure you run the inner slider first, otherwise the height of the inner slider container will be wrong. |
| freezable | Boolean |
Default: true. Indicate whether the slider will be frozen (controls, nav, autoplay and other functions will stop work) when all slides can be displayed in one page. |
| disable | Boolean |
Default: false. Disable slider. |
| startIndex | positive integer |
Default: 0. The initial index of the slider. |
| onInit | Function | false |
Default: false. Callback to be run on initialization. |
| useLocalStorage | Boolean |
Default: true. Save browser capability variables to localStorage and without detecting them everytime the slider runs if set to true. |
| nonce | String / false |
Default: false. Optional Nonce attribute for inline style tag to allow slider usage without `unsafe-inline Content Security Policy source. |
NOTE: Prior to v2.0.2, options "container", "controlsContainer", "navContainer" and "autoplayButton" still need to be DOM elements. E.g. container: document.querySelector('.my-slider')
Responsive options
The following options can be redefined in responsive field: startIndex, items, slideBy, speed, autoHeight, fixedWidth, edgePadding, gutter, center, controls, controlsText, nav, autoplay, autoplayHoverPause, autoplayResetOnVisibility, autoplayText, autoplayTimeout, touch, mouseDrag, arrowKeys, disable
<script>
var slider = tns({
container: '.my-slider',
items: 1,
responsive: {
640: {
edgePadding: 20,
gutter: 20,
items: 2
},
700: {
gutter: 30
},
900: {
items: 3
}
}
});
</script>
NOTE:
- The breakpoints behave like (min-width: breakpoint) in CSS, so an undefined option will be inherited from previous small breakpoints.
- fixedWidth can only be changed to other positive integers. It can't be changed to negative integer, 0 or other data type.
5. METHODS
The slider returns a slider object with some properties and methods once it's initialized:
{
version: version, // tiny-slider version
getInfo: info(),
events: events, // Object
goTo: goTo(),
play: play(),
pause: pause(),
isOn: isOn, // Boolean
updateSliderHeight: updateInnerWrapperHeight(),
refresh: initSliderTransform(),
destroy: destroy(),
rebuild: rebuild()
}
To get the slider information, you can either use the getInfo() method or subscribe to an Event. Both return an Object:
{
container: container, // slider container
slideItems: slideItems, // slides list
navContainer: navContainer, // nav container
navItems: navItems, // dots list
controlsContainer: controlsContainer, // controls container
hasControls: hasControls, // indicate if controls exist
prevButton: prevButton, // previous button
nextButton: nextButton, // next button
items: items, // items on a page
slideBy: slideBy // items slide by
cloneCount: cloneCount, // cloned slide count
slideCount: slideCount, // original slide count
slideCountNew: slideCountNew, // total slide count after initialization
index: index, // current index
indexCached: indexCached, // previous index
displayIndex: getCurrentSlide(), // display index starts from 1
navCurrent: navCurrent, // current dot index
navCurrentCached: navCurrentCached, // previous dot index
pages: pages, // visible nav indexes
pagesCached: pagesCached,
sheet: sheet,
event: e || {}, // event object if available
};
getInfo
Get slider information.
slider.getInfo();
document.querySelector('.next-button').onclick = function () {
// get slider info
var info = slider.getInfo(),
indexPrev = info.indexCached,
indexCurrent = info.index;
// update style based on index
info.slideItems[indexPrev].classList.remove('active');
info.slideItems[indexCurrent].classList.add('active');
};
goTo
Go to specific slide by number or keywords.
slider.goTo(3);
slider.goTo('prev');
slider.goTo('next');
slider.goTo('first');
slider.goTo('last');
document.querySelector('.goto-button').onclick = function () {
slider.goTo(3);
};
play
Programmatically start slider autoplay when autoplay: true.
slider.play();
pause
Programmatically stop slider autoplay when autoplay: true.
slider.pause();
updateSliderHeight
Manually adjust slider height when autoHeight is true.
slider.updateSliderHeight();
destroy
Destroy the slider.
slider.destroy();
rebuild
Rebuild the slider after destroy.
slider = slider.rebuild(); // this method returns a new slider Object with the same options with the original slider
6. Custom Events
Available events include: indexChanged, transitionStart, transitionEnd, newBreakpointStart, newBreakpointEnd, touchStart, touchMove, touchEnd, dragStart, dragMove and dragEnd.
var customizedFunction = function (info, eventName) {
// direct access to info object
console.log(info.event.type, info.container.id);
}
// bind function to event
slider.events.on('transitionEnd', customizedFunction);
// remove function binding
slider.events.off('transitionEnd', customizedFunction);
