Locomotive Scroll - Detection of elements in viewport & smooth scrolling with parallax effects.

Source: github.com

1. INCLUDE JS AND CSS FILES

<script src="locomotive-scroll.min.js"></script>

2. HTML

<h1 data-scroll>Hey</h1>
<p data-scroll>Hey</p>

3. JAVASCRIPT

<script>
    (function () {
        var scroll = new LocomotiveScroll();
    })();
</script>

4. Instance options

Option	Type	Default	Description
el	object	document	Scroll container element.
name	string	'scroll'	Data attribute prefix (data-scroll-xxxx).
offset	array(2)	[0,0]	Global in-view trigger offset : [bottom,top] Use a string with % to use a percentage of the viewport height. Use a numeric value for absolute pixels unit. E.g. ["30%",0], [100,0], ["30%", 100]
repeat	boolean	false	Repeat in-view detection.
smooth	boolean	false	Smooth scrolling.
initPosition	object	{ x: 0, y: 0 }	An object defining the initial scroll coordinates on a smooth instance. For example: { x: 0, y: 1000 }
direction	string	vertical	Scroll direction: vertical or horizontal
lerp	number	0.1	Linear interpolation (lerp) intensity. Float between 0 and 1. This defines the "smoothness" intensity. The closer to 0, the smoother.
getDirection	boolean	false	Add direction to scroll event.
getSpeed	boolean	false	Add speed to scroll event.
class	string	is-inview	Element in-view class.
initClass	string	has-scroll-init	Initialize class.
scrollingClass	string	has-scroll-scrolling	Is scrolling class.
draggingClass	string	has-scroll-dragging	Is dragging class.
smoothClass	string	has-scroll-smooth	Has smooth scrolling class.
scrollbarContainer	object	false	Specifies the container element for the scrollbar to be appended in. If false, scrollbar will be appended to the body.
scrollbarClass	string	c-scrollbar	Scrollbar element class.
multiplier	number	1	Factor applied to the scroll delta, allowing to boost/reduce scrolling speed (regardless of the platform).
firefoxMultiplier	number	50	Boost scrolling speed of Firefox on Windows.
touchMultiplier	number	2	Multiply touch action to scroll faster than finger movement.
scrollFromAnywhere	boolean	false	By default locomotive-scroll listens for scroll events only on the scroll container (el option). With this option set to true, it listens on the whole document instead.
gestureDirection	string	vertical	Defines which gesture direction(s) scrolls in your instance. You can use : vertical horizontal both
tablet & smartphone	object		Object allowing to override some options for a particular context. You can specify: smooth direction horizontalGesture For tablet context you can also define breakpoint (integer, defaults to 1024) to set the max-width breakpoint for tablets.
reloadOnContextChange	boolean	false	Allows to reload the page when switching between desktop, tablet and smartphone contexts. It can be useful if your page changes a lot between contexts and you want to reset everything.
resetNativeScroll	boolean	true	Sets history.scrollRestoration = 'manual' and calls window.scrollTo(0, 0) on locomotive-scroll init in Native Class. Useful if you use transitions with native scrolling, otherwise we advise to set it to false if you don't want to break History API's scroll restoration feature.

5. Element attributes

Attribute	Values	Description
data-scroll		Detect if in-view.
data-scroll-id	string	(Optional) Useful if you want to scope your element and get the progress of your element in the viewport for example.
data-scroll-container		Defines the scroll container. Required for basic styling.
data-scroll-section		Defines a scrollable section. Splitting your page into sections may improve performance.
data-scroll-class	string	Element in-view class.
data-scroll-offset	string	Element in-view trigger offset : bottom,top First value is bottom offset, second (optional) is top offset. Percent is relative to viewport height, otherwise it's absolute pixels. E.g. "10", "100,50%", "25%, 15%"
data-scroll-repeat	boolean	Element in-view detection repeat.
data-scroll-call	string	Element in-view trigger call event.
data-scroll-position	string	top, bottom, left or right Window position of in-view trigger.
data-scroll-speed	number	Element parallax speed. A negative value will reverse the direction.
data-scroll-delay	number	Element's parallax lerp delay.
data-scroll-direction	string	Element's parallax direction. vertical or horizontal
data-scroll-sticky		Sticky element. Starts and stops at data-scroll-target position.
data-scroll-target	string	Target element's in-view position.

6. Instance methods

Method	Description	Arguments
init()	Reinitializes the scroll.
on(eventName, function)	Listen instance events ⬇.
update()	Updates all element positions.
destroy()	Destroys the scroll events.
start()	Restarts the scroll events.
stop()	Stops the scroll events.
scrollTo(target, options)	Scroll to a target.	target: Defines where you want to scroll. Available values types are : node : a dom element string : you can type your own selector, or use values "top" and "bottom" to reach scroll boundaries int : An absolute scroll coordinate in pixels options (optional, object) : Settings object. Available values are: offset (integer) : Defines an offset from your target. E.g. -100 if you want to scroll 100 pixels above your target callback (function) : Called when scrollTo completes (note that it won't wait for lerp to stabilize) duration (integer) : Defines the duration of the scroll animation in milliseconds. Defaults to 1000 easing (array) : An array of 4 floats between 0 and 1 defining the bezier curve for the animation's easing. Defaults to [0.25, 0.00, 0.35, 1.00] See https://greweb.me/2012/02/bezier-curve-based-easing-functions-from-concept-to-implementation Keep in mind this will also be affected by the lerp unless you set disableLerp to true. disableLerp (boolean) : Lerp effect won't be applied if set to true

7. Instance events

Event	Arguments	Description
scroll	obj	Returns scroll instance (position, limit, speed, direction and current in-view elements).
call	func	Trigger if in-view. Returns your string or array if contains ,.
